UTK-615AP-VFW80 15.6" Compact, Lightweight Self-Service Kiosk (WHITE)

  1. ARM CortexTM-A17 RK3288 processor
  2. 2GB RAM, 8GB eMMC, Android 8.1 OS
  3. Built-in camera, scanner, Wi-fi/Bluetooth, NFC reader, 80 mm thermal printer
  4. Fully-integrated functionality
  5. Optional swappable battery for mobility solution
  6. Eye-catching LED light trim
Certifications
CE CE CE CE
Please visit via PC to place order/quote

$877.85

Make an inquiry Add to Quote Add to Cart
Features
Hot-Swappable Battery Module

  • Supports 7 ~ 9 hours of operation
  • Eliminates complex wiring
  • Facilitates mobile applications when combined with a floor stand on wheels
Eye-Catching LED Indicators

  • Attract customer attention and engagement
  • Ensure easy device navigation and operation
  • Improve satisfaction with self-service applications
Omni Management Remote Access Efficient Operation
  • Support Windows /Android OS
  • Manages batteries, scanners,
    cameras, NFC readers, and thermal printers
  • Open APIs enable integration
  • Real-time monitoring
  • Remote power, audio, backlight, and software control
  • Remote troubleshooting
  • OTA system/software updates
  • Supports one-to-many batch control
  • Templates accelerate setup and deployment
Specifications
Category
Attribute
Value
Processor System
CPU
Rockchip ARM Cortex™-A17 RK3288 1.6 GHz
Processor System
OS
Android 8.1
Processor System
RAM
2G DDR3L installed
Processor System
Storage
8GB of on board eMMC
Display
Brightness
220 cd/m²
Display
Max. Resolution
FHD (1920 x 1080)
Display
Size
15.6" TFT LCD
Touch Screen
Type
Projected Capacitive
Color
Color
White
I/O Interface
Ethernet
1 x RJ-45 Gigabit Ethernet (10/100/1000)
I/O Interface
Extendable Slot
1 x Micro SD, 1 x SIM
I/O Interface
Serial Port
1 x COM (RS-232)
I/O Interface
Speaker
2 x 2W Speaker
I/O Interface
USB Port
1 x USB 2.0
Power
Input Rating
12 V/5 A (60 W ITE Adapter)
Environment
Operating Humidity
10 ~ 95% @ 40°C non-condensing
Environment
Operating Temperature
0~40° C
Peripheral
Barcode Scanner
1D/2D Barcode Scanner
Peripheral
Battery Pack
8400 mAh battery pack (optional)
Peripheral
Bluetooth
Bluetooth® v4.2
Peripheral
Camera
720p web camera module; Structured-light 3D scanner (optional)
Peripheral
GPS
LTE + GPS communication module (optional)
Peripheral
NFC/RFID Reader
optional
Peripheral
Printer
80 mm thermal printer (default); 58 mm thermal printer (optional)
Peripheral
Smart Card Reader
optional
Recommended Peripherals

Accessory Products

Part No. Description Unit Price(USD) Qty
1700013977 Power Cord CCC 3P 10A 250V 200cm 90° $2.14
1700018704 Power Cord BSI 3P 10A 250V 180cm $8.92
17AP164900518011 POWER CORD CEE 7/16+C13 L1.8M $2.42
1700001714 Power Cord BSMI 3P 7A 125V 183cm $3.32
Part No. Qty
1700013977
Power Cord CCC 3P 10A 250V 200cm 90°
Unit Price(USD): $2.14
1700018704
Power Cord BSI 3P 10A 250V 180cm
Unit Price(USD): $8.92
17AP164900518011
POWER CORD CEE 7/16+C13 L1.8M
Unit Price(USD): $2.42
1700001714
Power Cord BSMI 3P 7A 125V 183cm
Unit Price(USD): $3.32
